1080P vehicle wireless camera with built-in rechargeable battery and magnet base

1080P vehicle wireless camera with built-in rechargeable battery and magnet base

HDW897

STONKAM HD wireless reversing camera with strong magnet is simple and convenient to install. With rechargeable battery, it can be powered by battery; the open transmission distance is up to 984ft, and the signal is stable and anti-interference. In addition, this vehicle wireless camera is waterproof and dustproof up to IP69K, and also has night vision, high reliability, wide applicability, can be widely used in cargo trucks, cranes, excavators, agricultural trucks and other vehicles.

Inquire Now

STONKAM® exclusively serves businesses. Please ensure accurate company email and country/region information. We will respond to you as quickly as possible!

Features

【1080P HD wireless vehicle monitoring camera】 With 1080P CMOS imageacquisition sensor, you can clearly view the situation around the vehicle. The device also has night vision function, which provides you with a clear vision for 24 hours.

【Easy installation】 With magnet base, STONKAM HD Wireless Camera can be installed without drilling. The range of available vehicles is wide and the flexibility is high.

【Transmission distance up to 984ft】 The open transmission distance is as far as 984ft, and the signal is stable and anti-jamming. Even in high-speed or long-distance operation, the monitor will display the surrounding environment in real time, making your driving or operation more convenient without interference, flicker, blur or delay.

【Rechargeable camera】 With rechargeable battery, the endurance is up to 12 hours, automatic standby, reduce power consumption. Meanwhile, it has over-charging protection and over-discharging protection to protect the battery performance.

【Waterproof】The wireless monitoring camera on the vehicle is waterproof IP69K, no matter whether it is rainy, snowy or foggy, the camera will not be affected.

【Night vision】Correct color deviation during the day and protect driving safety at night.

Wireless vehicle monitoring camera:

Battery Capacity	3.6V/6400mAh
Charging Voltage	5V-12V
Charging Time	5V/8H，12V/3H
Charging Current	5V/1.5A(MAX)，12V/1.5A(MAX)
Discharging Time	12H（daytime） 5H（night）
Charging Temperature	0~+40℃
Discharging Temperature	-20~+60℃
Storage Temperature	-20~+60℃
Waterproof Rating	IP69K
Dimension	116 x 80 x 66（mm）
Weight	670g
Sensor	1/2.9” CMOS SENSOR
Effective Pixels	1920 x 1080 pixels
AGC	Auto
Signal to Noise Ratio	38dB
White Balance	Auto
BLC	Auto
Operation Frequency	2048-2478MHZ
Transmission Distance (barrier free)	300m(20dBm)
Receiving sensitivity	-78dBm
Video Decode	H.264
Transmission power	10dBm/20dBm/16dBm
Modulation	FHSS
Delay	170ms
RF Bit Rate	12Mbps
Minimum Illumination	0Lux
Night Vision Distance	8-10m
Audio	Optional
Viewing Angle	70°/100°/110°130°
IR-cut function	Optional

What are the benefits of STONKAM® 7-inch HD Wireless Vehicle Monitoring System?

1080P HD wireless vehicle monitoring camera

With 1080P CMOS imageacquisition sensor, you can clearly view the situation around the vehicle. The device also has night vision function, which provides you with a clear vision for 24 hours.

With magnetic base, no drilling, no wiring, easy installation!

With magnet base, STONKAM HD Wireless Camera can be installed without drilling. The range of available vehicles is wide and the flexibility is high.

STONKAM HD Wireless Camera

Open transmission distance up to 984ft

Even in high-speed or long-distance operation, the monitor will display the surrounding environment in real time, making your driving or operation more convenient without interference, flicker, blur or delay.

Wireless vehicle monitor

Rechargeable camera, ultra-low standby power consumption

Meanwhile, it has over-charging and over-discharging protection to protect the battery performance.

Built-in antenna and waterproof shell, beautiful and durable

The wireless vehicle monitoring monitor adopts IP66 waterproof shell, and the antenna is built in, which is beautiful and durable. The wireless monitoring camera on the vehicle is waterproof IP69K, no matter whether it is rainy, snowy or foggy, the camera will not be affected.

Correct color deviation during the day and protect driving safety at night

STONKAM 1080P Vehicle Wireless Rechargeable Camera can support IR-CUT, thoroughly solving the problem of color deviation of green plants under sunlight and ensuring clear recording; And the night vision distance is up to 10 meters, ensuring safe driving!

1080P Vehicle Wireless Rechargeable Camera

Wireless vehicle monitor

Multiple Application Scenarios

With top grade high quality, STONKAM® HD Digital Wireless Vehicle Monitor System can be applied to various vehicles, such as forklift, crane, harvester, etc.


Harvester	Excavator

Farm	Forklift

Crane	Planter

Applications

STONKAM 7-inch vehicle wireless monitor can be applied to all kinds of vehicles through simple installation without wiring, and combined with high-definition vehicle wireless camera to form a perfect 7-inch high-definition wireless vehicle monitoring system.

STONKAM® exclusively serves businesses. Please ensure accurate company email and country/region information. We will respond to you as quickly as possible!

Features

【1080P HD wireless vehicle monitoring camera】 With 1080P CMOS imageacquisition sensor, you can clearly view the situation around the vehicle. The device also has night vision function, which provides you with a clear vision for 24 hours.

【Easy installation】 With magnet base, STONKAM HD Wireless Camera can be installed without drilling. The range of available vehicles is wide and the flexibility is high.

【Rechargeable camera】 With rechargeable battery, the endurance is up to 12 hours, automatic standby, reduce power consumption. Meanwhile, it has over-charging protection and over-discharging protection to protect the battery performance.

【Waterproof】The wireless monitoring camera on the vehicle is waterproof IP69K, no matter whether it is rainy, snowy or foggy, the camera will not be affected.

【Night vision】Correct color deviation during the day and protect driving safety at night.

Wireless vehicle monitoring camera:

Battery Capacity

3.6V/6400mAh

Charging Voltage

5V-12V

Charging Time

5V/8H，12V/3H

Charging Current

5V/1.5A(MAX)，12V/1.5A(MAX)

Discharging Time

12H（daytime） 5H（night）

Charging Temperature

0~+40℃

Discharging Temperature

-20~+60℃

Storage Temperature

-20~+60℃

Waterproof Rating

IP69K

Dimension

116 x 80 x 66（mm）

Weight

670g

Sensor

1/2.9” CMOS SENSOR

Effective Pixels

1920 x 1080 pixels

AGC

Auto

Signal to Noise Ratio

38dB

White Balance

Auto

BLC

Auto

Operation Frequency

2048-2478MHZ

Transmission Distance (barrier free)

300m(20dBm)

Receiving sensitivity

-78dBm

Video Decode

H.264

Transmission power

10dBm/20dBm/16dBm

Modulation

FHSS

Delay

170ms

RF Bit Rate

12Mbps

Minimum Illumination

0Lux

Night Vision Distance

8-10m

Audio

Optional

Viewing Angle

70°/100°/110°130°

IR-cut function

Optional

What are the benefits of STONKAM® 7-inch HD Wireless Vehicle Monitoring System?

1080P HD wireless vehicle monitoring camera

With 1080P CMOS imageacquisition sensor, you can clearly view the situation around the vehicle. The device also has night vision function, which provides you with a clear vision for 24 hours.

With magnetic base, no drilling, no wiring, easy installation!

With magnet base, STONKAM HD Wireless Camera can be installed without drilling. The range of available vehicles is wide and the flexibility is high.

Open transmission distance up to 984ft

Even in high-speed or long-distance operation, the monitor will display the surrounding environment in real time, making your driving or operation more convenient without interference, flicker, blur or delay.

Rechargeable camera, ultra-low standby power consumption

Meanwhile, it has over-charging and over-discharging protection to protect the battery performance.

Built-in antenna and waterproof shell, beautiful and durable

The wireless vehicle monitoring monitor adopts IP66 waterproof shell, and the antenna is built in, which is beautiful and durable. The wireless monitoring camera on the vehicle is waterproof IP69K, no matter whether it is rainy, snowy or foggy, the camera will not be affected.

Correct color deviation during the day and protect driving safety at night
