7-inch HD Rear View Monitor
(Model:HD-261D)
7-inch HD Rear View Monitor
Features
  •  Support 4CH x 1080P / 720P cameras
  •  Video Input: 4 x Aviation Port,  4 x Trigger
  •  Contrast: 800:1
  •  Resolution: 1024*600
  •  Brightness: 600cd/m2
  •  Power consumption: approx. 8W
  •  DC: 10-32V


7-inch HD Rear View Monitor


Specification
Description HD 7" Color monitor
Resolution 1024 x 3(RGB) x 600
Anti-vibration ISO 16750-3 Max. 6.3G
Maximum Number of Cameras 4
Audio input 4
Audio output (loudspeaker) 1W
Trigger 5
Max. Brightness 450 cd/m²
Contrast 800:1
Minimum Operating Temperature -20ºC, RH 90%
Maximum Operating Temperature +70ºC, RH 90%
Viewing Angle Monitor U: 70/ D: 75, R/L: 75/75
Monitor Diameter (mm) 203mm (W) × 112mm (H) × 28mm (T).
Split Screen No
Volts 10-32V
Consumption less than 6W (without cameras)
Product Video

Applications

7-inch HD Rear View Monitor

7-inch HD Rear View Monitor

Accessories





Sun Shield

U- Support Bracket (Optional) Angle Adjustment Screws (Optional)

Center Mount Bracket (Optional)

Extention Cable





Power Cable
IR Remote Control
