7-inch Digital Quad Waterproof Monitor
7-inch Digital Quad Waterproof Monitor
  •  7 inches Digital Quad waterproof Monitor, waterproof capacity equal to IP66 standard
  •  Picture image may be adjusted for Horizontal, Vertical, Mirror and Normal viewing; characters of the menu will not  inverse when set to mirror image.
  •  Single, dual, triplex, quad, trefoil, Y-split image and PIP functions available.
  •  System format: NTSC/PAL
  •  Five trigger lines; once a trigger line is activated, image automatically switches to its corresponding camera.
  •  Trigger priority is available
  •  Auto scan, scan channel and time can be set according to the users’ demand.
  •  Reverse warning yardstick, can be adjusted up and down, left and right
  •  Touch screen available, can recognize down, left, right side “swipe”; support two-point touch to realize channel  switching.
  •  Support level 5 LCD manual backlight adjustment ,level 3 automatic adjustment
  •  Easy installation and convenient operation, with innovative functions.
  •  Applicable to indoor / outdoor security systems, vehicle and ship surveillance.
  •  22-Pin:4 AV inputs,1 video output, 1 AV video input,1 audio output,and 1 AUX audio input
Audio output 1W
Power supply Automobile storage battery (10-32v)
ISO 16750-3 (Max.6.3G)
Power consumption Max.25w
Outer dimension  182mm(W)×122mm(H)×43mm(T) :
Dot pitch
0.1790 (H)× 0.0642 (V)
800×3 (RGB)×480
Contrast 500:1
Brightness 400cd/m²
Viewing angle U: 50°,D: 70°, R/L: 70°/70°
Operating temperature -20ºC~+70ºC,RH90%
Storage temperature -30ºC~+80ºC,RH90%
Distance Label
7 inches Digital Touch-Control waterproof Monitor-Distance Label
