7 Inch HD Wireless Forklift Monitoring System
HDW125Q, HDW814P, HDW897, AC552
Forklift camera systems have become a standard aid to forklift driver operations, providing improved safety and range of vision when maneuvering and storing loads, so drivers can work safer and more efficent. STONKAM 1080P HD wireless forklift camera has stable signal and its transmission range of up to 120 meters. It has 62° viewing angle, will increase the visibility range, solve blind spots problems and avoid accidents, and also improve operational efficiency.
Inquire Now
LCD Dimension |
7" |
Resolution |
1024x 3 (RGB) x600 |
Contrast |
700:1 |
Brightness |
650cd/m² |
Viewing Angle |
U:85 / D:85, R/L:85 |
Aspect Ratio |
16:9 |
Channel |
4 CH |
Operating Frequency |
2408MHz ~ 2478MHz(ISM band) |
Receiving Sensitivity |
-78dBm |
Transmission Power |
FCC≤26dBmCE≤20dBmMIC≤10dBm |
Decompression Form |
H.264 |
Modulation |
FHSS |
Delay |
130ms |
Transmission Distance |
FCC≤300 MCE≤200 MMIC≤60 M |
System Format |
PAL / NTSC |
Power Supply |
DC 10-32V |
Power Consumption |
Max.10W |
Loudspeaker |
1.5W/8Ω |
Operating Temp. & Humidity |
-20~+70ºC,RH90%MAX |
Storage Temp. & Humidity |
-30~+80ºC,RH90%MAX |
Image Device |
1/2.9" CMOS |
Effective Pixels |
1920 (H) x 1080 (V) |
Signal to Noise Ratio |
38dB |
White Balance |
Auto |
BLC |
Auto |
Dynamic Range |
81dB |
Operation Frequency |
2403MHz-2478MHz |
Transmission Distance (Barrier Free) |
120m(Max) |
Receiving Sensitivity |
-78dBm |
Video Code |
H.264 |
Transmission Power |
FCC:≤26dBm CE:≤20dBm MIC:≤10dBm |
Modulation |
FHSS |
Delay |
130ms |
RF Bit Rate |
12Mbps |
Operating Temp. & Humidity |
–20℃ ~ 70℃, RH95%MAX. |
Storage Temp. & Humidity |
–30℃ ~ 80℃, RH95%MAX. |
Minimum Illumination |
0Lux/0.1Lux |
Power Supply |
DC10-32V |
Power Consumption |
Day:1.8W-2.5W Night:3.6W-4.3W |
Night Vision Distance |
3-5M |
Waterproof Rating |
IP69K |
Audio |
No |
Viewing Angle |
62° |
Heater |
No |
IR-Cut Function |
No |
Image Mode |
Mirror/Normal |
Battery Capacity |
3.6V/6400mAh |
Charging Voltage |
5V-12V |
Charging Time |
5V/8H,12V/3H |
Charging Current |
5V/1.5A(MAX),12V/1.5A(MAX) |
Discharging Time |
12H(daytime) 5H(night) |
Charging Temperature |
0~+40℃ |
Discharging Temperature |
-20~+60℃ |
Storage Temperature |
-20~+60℃ |
Waterproof Rating |
IP69K |
Dimension |
116 x 80 x 66(mm) |
Weight |
670g |
Sensor |
1/2.9” CMOS SENSOR |
Effective Pixels |
1920 x 1080 pixels |
AGC |
Auto |
Signal to Noise Ratio |
38dB |
White Balance |
Auto |
BLC |
Auto |
Operation Frequency |
2403-2478MHZ |
Transmission Distance (barrier free) |
300m(20dBm) |
Receiving Sensitivity |
-78dBm |
Video Decode |
H.264 |
Transmission Power |
10dBm/20dBm |
Modulation |
FHSS |
Delay |
170ms |
RF Bit Rate |
12Mbps |
Minimum Illumination |
0Lux |
Night Vision Distance |
8-10m |
Audio |
Optional |
Viewing Angle |
130° |
IR-Cut Function |
Optional |
